RV MPPT Solar Charge Controller
Created with Pixso.

Flush Mount RV MPPT Solar Charge Controller with 5 Stage Charging BMS Wake Up and Lead Acid Battery Compatibility

Name

Flush Mount RV MPPT Solar Charge Controller with 5 Stage Charging BMS Wake Up and Lead Acid Battery Compatibility

Brand Name: Melin Sunergy
Model Number: MT518-40AFM
MOQ: 100
Payment Terms: TT,West Union
Supply Ability: 5000pcs per month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE ,FCC ,UKCA
Mounting:
Flush Mount
Warranty:
2 Years
Dimension:
179X144X76mm
System Voltage:
12V/24V
Maximum Current:
40A
Protection:
Overcharging ,undercharging,shor T Circuit,reverse Polarity
Work Temperature:
-25~+50 Degree
Temperature Compensation:
Yes
Supply Ability:
5000pcs per month
Highlight:

RV MPPT Solar Charge Controller 12V

,

RV MPPT Solar Charge Controller 24V

,

Flush Mount Solar Charge Controller 12V

Product Description
Flush Mount RV MPPT Solar Charge Controller 12V 24V With Overcharging Short Circuit Protection
Product Overview
The Flush Mount 12V/24V RV 40A MPPT Controller provides advanced solar charging with overcharging and short circuit protection. With a maximum current of 40A, this versatile controller supports various solar panels, delivering 570W for 12V systems and 1140W for 24V systems. Its BMS Wake Up feature ensures optimal battery charging and longevity.
Key Features
  • 40A maximum current capacity
  • Supports 12V/24V auto-switching systems
  • Maximum input voltage: 100V
  • Operating temperature range: -25°C to +50°C
  • Compact dimensions: 179×144×76mm
  • 5-stage charging process
  • MPPT tracking efficiency up to 99.5%
  • Includes Bluetooth connectivity
Technical Specifications
Product Name Flush Mount 40A MPPT Controller for RV
Product Type Intelligent MPPT solar controller
Rated Current 40A
Maximum PV Power 580W @12V, 1160W @24V
System Voltage 12V/24V Auto working
Charging Efficiency 98%
Battery Compatibility Lead Acid (AGM, GEL, WET), Lithium (LiFePO4, LTO, LCO), Custom
Display LCD + LED display
Protection Rating IP43
Dimensions 195×130×70mm
Weight 1090g
Warranty 2 Years
Applications
The MT518-40AFM controller is ideal for RV solar systems, compatible with various battery types including AGM, GEL, WET, and lithium variants. Its IP43 rating ensures durability in diverse weather conditions. The integrated Bluetooth allows remote monitoring and configuration via smartphone, while the BMS wake-up feature protects against overcharging and short circuits.
