Digital Solar Charge Controller
Created with Pixso.

40A PWM Solar Controller with 2-Year Warranty IP22 Rated and Temperature Compensation for 12V-24V Systems

Name

40A PWM Solar Controller with 2-Year Warranty IP22 Rated and Temperature Compensation for 12V-24V Systems

Brand Name: Melin Sunergy
Model Number: MT515-40A
MOQ: 100
Supply Ability: 5000pcs per month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE ,FCC ,UKCA
Max. PV Power.:
760W @ 12V ,1520W @ 24V
Temperature Compensation:
Yes
BMS Wake Up:
Yes
Remote Display:
Optional
Protection:
Overcharge/Short Circuit/Reverse Polarity/Over Temperature
Charging Stage:
5 Stage Charging
Maximum Input Voltage:
50V
Warranty:
2 Years
Charging Current:
40A
Supply Ability:
5000pcs per month
Highlight:

Flush Mount PWM Based Solar Charge Controller

,

Smart PWM Based Solar Charge Controller

,

5 Stage Solar Charge Controller 40A

Product Description
5 Stage Smart Flush Mount PWM Based Solar Charge Controller 40A For 12V - 24V Systems
Premium Solar Charge Controller with Advanced Features
Our 40A Solar Charge Controller delivers reliable performance with a 2-year warranty. Featuring temperature compensation for optimal battery charging and an LCD+LED display for easy system monitoring, this controller is built for efficiency and longevity. Its 40A capacity makes it suitable for both small off-grid setups and large residential solar systems.
Key Features
  • Digital Solar Charge Controller with PWM technology
  • Compact dimensions: 182*103*50mm
  • Maximum PV Power: 760W @ 12V, 1520W @ 24V
  • 2-year manufacturer warranty
  • Clear LCD+LED display for system monitoring
  • IP22 rated for basic protection
  • 40A capacity for demanding solar systems
Technical Specifications
Item No. MT515-40A
Rated Current 40A
Max. Solar Power Input 760W @12V system, 1520W @24V
Nominal Solar Input Voltage 15~22V DC
Max. Solar Input Voltage 25V DC
Charging Stage 5 Stage Charging (Soft Start-Bulk-Absorption-Equalization-Float)
Battery Type 6 Types (AGM, GEL, WET, Calcium, LTO & LiFePO4)
Protection Features Over Charge, Input & Output Reverse Polarity, Short Circuit, Over temperature
IP Rating IP22
Operation Temperature -25~50℃/-13~122℉
Applications
The MT515-40A digital solar charge controller is ideal for residential, commercial, and off-grid solar power systems. Perfect for solar street lights, water pumps, refrigerators, and other solar-powered devices. Its compact size (182*103*50mm) and easy installation make it suitable for both professional installations and DIY solar projects.
40A PWM Solar Controller with 2-Year Warranty IP22 Rated and Temperature Compensation for 12V-24V Systems 0
