MPPT Solar Charge Controller
Created with Pixso.

40A 12V/24V RV MPPT Solar Charge Controller with 100V Maximum Input for Efficient Solar Power Management

40A 12V/24V RV MPPT Solar Charge Controller with 100V Maximum Input for Efficient Solar Power Management

Brand Name: Melin Sunergy
Model Number: MT518-40A
MOQ: 100
Payment Terms: TT,West Union
Supply Ability: 5000pcs per month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE ,FCC ,UKCA
Warranty:
2 Years
Work Temperature:
-25~+50 Degree
Mounting:
Surface Mount
System Voltage:
12V/24V
BMS Wake Up:
Yes
Bluetooth:
Optional
Suitable Battery Type:
AGM ,GEL ,WET, Calcium ,Lead Crystal , LTO ,LCO ,LFP ,Customs
Display:
LCD Display
Rated Current:
40A
Supply Ability:
5000pcs per month
Highlight:

12V RV MPPT Solar Charge Controller

,

24V RV MPPT Solar Charge Controller

,

24V 40A MPPT Solar Charge Controller

Product Description
LCD Display 12V/24V 40A RV MPPT Solar Charge Controller with BMS Wake Up Technology
Upgrade your RV or off-grid solar system with our efficient 40A MPPT Solar Charge Controller. Featuring an LCD display for real-time monitoring, this controller supports multiple battery types and offers advanced BMS wake-up technology for optimal battery protection.
Key Features
  • 40A MPPT solar charge controller with LCD display
  • Supports 12V/24V systems (auto-detection)
  • Maximum PV input: 570W (12V) / 1140W (24V)
  • Compatible with multiple battery types: AGM, GEL, WET, Calcium, Lead Crystal, LTO, LCO, LFP
  • BMS wake-up technology for battery protection
  • Optional Bluetooth connectivity available
  • Surface mount design with sleek black finish
Technical Specifications
Parameter Specification
Product Type Intelligent MPPT solar controller
Charging Stage 5 Stage
Rated Current 40A
Maximum PV Input Power 580W @12V, 1160W @24V
Maximum Input Voltage 100V Voc
MPPT Tracking Efficiency 99.5%
Charging Conversion Efficiency 98%
Display LCD + LED display
Protection Rating IP43
Dimensions 195×130×70mm
Weight 1090g
Warranty 2 Years
Applications
Ideal for RVs, camping, off-grid living, and mobile homes. The controller's advanced features and robust design make it perfect for demanding environments where reliable solar power is essential.
MPPT Solar Charge Controller 40A with LCD display
