products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Digital Solar Charge Controller
Created with Pixso.

50A PWM Solar Regulator with BMS Wake Up for AGM GEL WET Calcium LiFePO4 LTO Batteries Digital Solar Charge Controller

Name

50A PWM Solar Regulator with BMS Wake Up for AGM GEL WET Calcium LiFePO4 LTO Batteries Digital Solar Charge Controller

Brand Name: Melin Sunergy
Model Number: MT515
MOQ: 100
Supply Ability: 5000pcs per month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE ,FCC ,UKCA
Dimensions:
182X103X50mm
IP Level:
IP22
Max. PV Power.:
1140W @ 12V ,2280W @ 24V
Display:
LCD+LED
Protection:
Overcharge/Short Circuit/Reverse Polarity/Over Temperature
Type:
PWM Controller
Battery Type:
AGM ,GEL ,WET,Calcium ,LiFePO4 ,LTO
System Voltage:
12V 24V
Rated Current:
60A
Supply Ability:
5000pcs per month
Highlight:

IP22 PWM Solar Regulator

,

60A PWM Solar Regulator

Product Description
LCD LED IP22 60A 50A PWM Solar Regulator For AGM GEL WET Calcium LiFePO4 LTO Batteries
Product Description
The Digital Solar Charge Controller features BMS Wake Up technology to automatically activate and deactivate your solar power system's battery management system. This extends battery life and ensures maximum charge capacity.
With temperature compensation, the regulator adjusts charging voltage based on environmental conditions to prevent overcharging or undercharging. Its sleek black design complements any solar power system and supports multiple battery types including AGM, GEL, WET, Calcium, LiFePO4, and LTO.
This 50A PWM solar regulator uses pulse width modulation technology to optimize power output from solar panels, reducing energy waste and improving system efficiency.
Key Features
  • Digital Solar Charge Controller with 5-stage charging
  • IP22 protection rating
  • Compact dimensions: 182*103*50mm
  • BMS Wake Up functionality
  • Optional remote display
  • 60A solar charge capacity
  • Automatic voltage regulation
Technical Specifications
Item No. MT515-60A
Rated Current 60A
Max. Solar Power Input 1140W@12V system, 2280W@24V
Nominal Solar Input Voltage 15~44V DC
Max. Solar Input Voltage 50V DC
Charging Stage 5 Stage Charging (Soft Start-Bulk-Absorption-Equalization-Float)
Battery Type 6 Types (AGM, GEL, WET, Calcium, LTO & LiFePO4)
Protection Features Over Charge, Input & Output Reverse Polarity, Short Circuit, Over temperature
Operation Temperature -25~50℃/-13~122℉
Applications
The MT515 solar regulator is ideal for off-grid systems, RVs, boats, and commercial solar installations. Its IP22 rating ensures durability in various weather conditions. The optional remote display provides convenient system monitoring.
With a minimum order quantity of 100 units and 5,000 units monthly production capacity, this regulator is available for delivery within 25 days.
