IP67 Waterproof Solar Charge Controller with 5 Stage Charging and LCD+LED Display for 12V 24V Systems

IP67 Waterproof Solar Charge Controller with 5 Stage Charging and LCD+LED Display for 12V 24V Systems

Brand Name:	Melin Sunergy
Model Number:	MT515
MOQ:	100
Supply Ability:	5000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE ,FCC ,UKCA

Display:

LCD+LED

Temperature Compensation:

Yes

IP Level:

IP22 Or IP67

Rated Current:

15A

System Voltage:

12V 24V

Color:

Black

Protection:

Overcharge/Short Circuit/Reverse Polarity/Over Temperature

Type:

PWM Controller

Supply Ability:

5000pcs per month

Highlight:

Waterproof Solar Charge Regulator

IP67 Solar Charge Regulator

Product Description

IP67 Waterproof Solar Charge Regulator 15A PWM For 12V 24V Solar Systems

IP67 Water Proof Black Solar Charge Regulator with 15A PWM and LCD LED Display, designed for 12V and 24V solar systems.

Product Overview

This charge controller supports both 12V and 24V system voltages, featuring a 5-stage charging process (bulk, absorption, float, equalization, and maintenance) for maximum efficiency and battery life. The black housing provides a sleek, modern appearance while the BMS wake-up function automatically activates the battery management system when voltage drops, protecting against overcharging and over-discharging.

Key Features

PWM Controller with 15A rated current
Supports 12V/24V system voltages
Built-in temperature compensation
Comprehensive protection: Overcharge/Short Circuit/Reverse Polarity/Over Temperature
Compatible with multiple battery types: AGM, GEL, WET, Calcium, LiFePO4, and LTO
IP67 waterproof rating for durable outdoor use
LCD+LED display for clear system monitoring

Technical Specifications

Item No.	MT515-15A
Rated Current	15A
Max. Solar Power Input	285W@12V system, 570W@24V
Nominal Solar Input Voltage	15~44V DC
Max. Solar Input Voltage	50V DC
Charging Stage	5 Stage Charging (Soft Start-Bulk-Absorption-Equalization-Float)
Battery Type	6 Types (AGM, GEL, WET, Calcium, LTO & LiFePO4)
Protection	Over Charge, Input & Output Reverse Polarity, Short Circuit, Over temperature
IP Rating	IP22 or IP67
Dimensions	130×102.6×35mm
Weight	250g
Operation Temperature	-25~50℃/-13~122℉

Applications

Ideal for residential/commercial solar systems, off-grid installations, mobile solar applications, outdoor lighting, remote cabins, and monitoring systems. Suitable for charging lead-acid, gel, and lithium batteries.
