15A Rated Current 5 Stage Charging IP22 or IP67 Rated PWM Solar Charge Controller with Digital LCD Display

15A Rated Current 5 Stage Charging IP22 or IP67 Rated PWM Solar Charge Controller with Digital LCD Display

Brand Name:	Melin Sunergy
Model Number:	MT515
MOQ:	100
Supply Ability:	5000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE ,FCC ,UKCA

Rated Current:

15A

BMS Wake Up:

Yes

Display:

LCD+LED

Protection:

Overcharge/Short Circuit/Reverse Polarity/Over Temperature

Type:

PWM Controller

Battery Type:

AGM ,GEL ,WET,Calcium ,LiFePO4 ,LTO

System Voltage:

12V 24V

Color:

Black

Supply Ability:

5000pcs per month

Highlight:

15A Digital Solar Charge Controller

Digital Solar Charge Controller Regulator

Product Description

LCD 12V 24V 15A PWM Digital Solar Charge Controller

This smart solar regulator efficiently manages power for both 12V and 24V systems, supporting lead acid and lithium batteries. With dimensions of 130×102.6×35mm, its compact design allows for flexible wall mounting or surface placement.

Key Features

Advanced LCD+LED display for clear system monitoring
Supports multiple battery types: AGM, GEL, WET, Calcium, LiFePO4, LTO
5-stage charging process (Soft Start-Bulk-Absorption-Equalization-Float)
BMS Wake Up feature automatically activates battery management
Comprehensive protection against overcharge, reverse polarity, and short circuits
Dual IP rating options (IP22 or IP67) for varied environmental conditions

Technical Specifications

Parameter	Value
Model Number	MT515-15A
Rated Current	15A
Max. Solar Input Power	285W @12V, 570W @24V
Input Voltage Range	15-44V DC (50V DC max)
Operation Temperature	-25°C to 50°C (-13°F to 122°F)
Dimensions	130×102.6×35mm
Weight	250g

Applications

Ideal for off-grid solar systems in RVs, boats, cabins, and small to medium solar installations. Certified with CE, FCC, and UKCA standards for reliable performance in diverse environments.
