12V 24V Digital Solar Charge Controller with 190W @ 12V 380W @ 24V and BMS Wake Up for AGM LFP Lithium Battery Systems

12V 24V Digital Solar Charge Controller with 190W @ 12V 380W @ 24V and BMS Wake Up for AGM LFP Lithium Battery Systems

Brand Name:	Melin Sunergy
Model Number:	MT515
MOQ:	100
Supply Ability:	5000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE ,FCC ,UKCA

Charging Stage:

5 Stage Charging

Maximum Input Voltage:

50V

Battery Type:

AGM ,GEL ,WET,Calcium ,LiFePO4 ,LTO

Color:

Black

System Voltage:

12V 24V

Max. PV Power.:

190W @ 12V ,380W @ 24V

Type:

PWM Controller

Rated Current:

10A

Supply Ability:

5000pcs per month

Highlight:

LFP Solar Battery Charge Regulator

AGM Solar Battery Charge Regulator

24V Solar Regulator For Lithium Battery

Product Description

12V 24V Solar Battery Charge Regulator For AGM LFP Lithium Battery Systems

Product Overview

This 5-stage charging PWM solar charge regulator efficiently manages power flow from solar panels to batteries. Available in IP22 (indoor) or IP67 (outdoor) protection ratings, it features a sleek black design suitable for residential and commercial solar installations.

Key Features

PWM Controller: Ensures precise energy regulation
BMS Wake Up: Automatically activates battery management system
Multi-Battery Support: Compatible with AGM, GEL, WET, Calcium, LiFePO4, and LTO batteries
Dual Voltage: Works with 12V and 24V systems
Robust Protection: IP22 or IP67 rated for various environments

Technical Specifications

Item No.	MT515-10A
Rated Current	10A
Max. Solar Power Input	190W@12V system, 380W@24V
Nominal Solar Input Voltage	15~44V DC
Max. Solar Input Voltage	50V DC
Charging Stage	5 Stage Charging (Soft Start-Bulk-Absorption-Equalization-Float)
Battery Type	6 Types (AGM, GEL, WET, Calcium, LTO & LiFePO4)
Protection	Over Charge, Input & Output Reverse Polarity, Short Circuit, Over temperature
Operation Temperature	-25~50℃/-13~122℉
Dimensions	130×102.6×35mm
Weight	250g

Applications

Ideal for off-grid solar systems, RVs, marine applications, and remote installations. Certified by CE, FCC, and UKCA with a 2-year warranty. Available in bulk quantities (minimum order 100 units) with 25-day lead time.
