700W PV Input 50A DC DC Charger with IP32 Protection for 12V Starter Battery

Name: 700W PV Input 50A DC DC Charger with IP32 Protection for 12V Starter Battery
Brand: Shenzhen Melin Sunergy Co., Ltd.
SKU: MD1250N05
Price: 126.00 USD
Availability: InStock

Brand Name:	Melin Sunergy
Model Number:	MD1250N05
MOQ:	10
Payment Terms:	TT,West Union
Supply Ability:	5000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE ,FCC ,UKCA

Max.Alternator Charging Current:

60A

MPPT Voltage Range:

17～36Vdc

Protection Degree:

IP32

Battery Voltage Range:

9~16Vdc

Max.Alternator Input Voltage:

13.2~16Vdc / 26.4~32Vdc Or 12~16Vdc / 24~32Vdc

Starter Battery Rated Voltage:

12/24Vdc

Rated Battery Voltage:

12Vdc

Max.PV Input Power:

700W

Supply Ability:

5000pcs per month

Highlight:

50A DC DC Charger

DC DC Charger IP32

12V Starter Battery Charger

Product Description

700W PV Input 50A DC DC Charger with IP32 Protection

This high-performance 12V DC DC charger features advanced MPPT technology with 99% tracking efficiency and robust IP32 protection. Designed for demanding industrial and automotive applications, it delivers reliable charging performance across extreme temperature ranges.

Key Features

Maximum PV Input Power: 700W
Advanced Communication: TTL, Remote Switch, Bluetooth with App
Versatile Alternator Charging Modes: Buck, Boost, Buck-Boost
Wide MPPT Voltage Range: 17-36V DC
Broad Battery Voltage Range: 9-16V DC
High-Efficiency Operation: Up to 98% conversion efficiency
Robust Construction: IP32 protection rating
Extended Temperature Range: -35°C to 65°C operation
Comprehensive 3-Year Warranty

Technical Specifications

Parameter	Specification
Model	MD1230N05
Max. PV Voltage (Open Circuit)	55V
MPPT Voltage Range	17-36V DC
Max. PV Input Current	27A
Max. PV Input Power	400W
Leisure Battery Types	Lead-acid / Li-ion / User Defined
Rated Leisure Battery Voltage	12V DC
Max. MPPT Charging Current	30A
Max. Alternator Charging Current	35A
Starter Battery Type	Lead Acid
Rated Starter Battery Voltage	12/24V DC
Weight	1.92kg (4.23 lb)
Dimensions	221×175.8×92.4mm (8.7×6.9×3.63in)
Protection Degree	IP32
Operating Temperature	-35°C to 65°C (-31°F to 149°F)

Applications & Certifications

The Melin Sunergy MD1250N05 DC DC Charger is CE, FCC, and UKCA certified, ensuring compliance with international quality standards. This versatile charger supports multiple battery types including lead-acid and lithium batteries, making it ideal for various applications:

Automotive starter battery charging systems
Marine and boat electrical systems
Recreational vehicle power management
Industrial backup power systems
Off-grid power solutions

Production & Delivery: Manufactured in China with a minimum order quantity of 10 units and delivery within 15 days. Monthly supply capacity: 5,000 units.
