50A DC DC Charger with Buck Boost Alternator Charging and IP32 Protection for Vehicles and Off-Grid Applications

Name: 50A DC DC Charger with Buck Boost Alternator Charging and IP32 Protection for Vehicles and Off-Grid Applications
Brand: Shenzhen Melin Sunergy Co., Ltd.
SKU: MD1250N05
Price: 126.00 USD
Availability: InStock

Brand Name:	Melin Sunergy
Model Number:	MD1250N05
MOQ:	10
Payment Terms:	TT,West Union
Supply Ability:	5000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE ,FCC ,UKCA

Max.Alternator Input Voltage:

13.2~16Vdc / 26.4~32Vdc Or 12~16Vdc / 24~32Vdc

Alternator Charging Mode:

Buck,Boost,Buck-Boost

Max.Alternator Charging Current:

60A

Protection Degree:

IP32

Warranty:

3 Years

Weight:

2.15kg（4.73lb

Battery Voltage Range:

9~16Vdc

COMMUNICATION:

TTL、Remote Switch,Bluetooth (with APP)

Supply Ability:

5000pcs per month

Highlight:

50A DC DC Charger IP32

Lightweight DC DC Charger

Product Description

Lightweight 50A DC DC Charger With Buck Boost Alternator Charging IP32 Protection

The DC DC Charger is engineered to perform reliably in extreme temperature conditions, operating from -35°C to 65°C (-31℉ to 149℉). This robust design makes it an ideal power solution for demanding environments where conventional chargers may fail.

Featuring IP32 protection, the charger effectively resists dust ingress and water splashes, ensuring long-term durability and reliable performance in various conditions.

Advanced communication capabilities include TTL, remote switch, and Bluetooth with dedicated app support, providing flexible control and monitoring options tailored to your specific requirements.

Compatible with 12/24Vdc starter batteries, this versatile DC DC charger serves multiple applications including electric vehicles, portable devices, and various automotive systems.

Key Features

Product Name: DC DC Charger
Protection Degree: IP32
Max. Alternator Charging Current: 60A
Rated Battery Voltage: 12Vdc
Communication: TTL, Remote Switch, Bluetooth (with APP)
MPPT Voltage Range: 17～36Vdc
DC to DC Charger with Solar Input
DC DC Charger 50A

Technical Specifications

Parameter	Specification
Model	MD1230N05
Max. PV Voltage of Open Circuit	55V
MPPT Voltage Range	17～36Vdc
Max. PV Input Current	27A
Max. PV Input Power	400W
Leisure Battery Type	Lead-acid / Li-ion / User Defined
Rated Leisure Battery Voltage	12Vdc
Leisure Battery Voltage Range	9~16Vdc
Max. MPPT Charging Current	30A
Max. Alternator Charging Current	35A
Starter Battery Type	Lead Acid
Rated Starter Battery Voltage	12/24Vdc
Max. Alternator Input Voltage (Conventional)	13.2~16Vdc / 26.4~32Vdc
Max. Alternator Input Voltage (Euro 6 Standard)	12~16Vdc / 24~32Vdc
Alternator Charging Mode	Buck, Boost, Buck-Boost
MPPT Tracking Efficiency	>99%
Max. Charging Conversion Efficiency	98%
Communication	TTL, Remote Switch, Bluetooth (with APP)
Weight	1.92kg (4.23 lb)
Dimensions	221×175.8×92.4mm (8.7×6.9×3.63in)
Protection Degree	IP32
Operating Temperature Range	-35°C~65°C (-31℉～149℉)
Warranty	3 Years

Applications

The Melin Sunergy MD1250N05 is a DC to DC charger with solar input capability, designed for charging 12Vdc battery systems in vehicles, marine applications, and off-grid installations.

Caravanning and Camping: Ideal for extended off-grid camping with solar input capability for daytime battery recharging.
Off-Road Vehicles: Charges auxiliary batteries in 4x4s, ATVs, and dirt bikes to power accessories without draining the main battery.
Marine Applications: Suitable for boats and yachts, providing reliable charging during long-term anchoring without engine use.
Emergency Response Vehicles: Ensures critical equipment remains operational in ambulances, fire trucks, and command centers.
Remote Installations: Powers weather stations, telecommunications equipment, and monitoring systems in locations without mains power access.

The MD1250N05 delivers maximum 50A output with a battery voltage range of 9~16Vdc and MPPT voltage range of 17～36Vdc. Certified to CE, FCC, and UKCA safety standards.
