30A IP32 Protection Lightweight DC DC Charger MPPT Solar Charger for 12/24Vdc Batteries

30A IP32 Protection Lightweight DC DC Charger MPPT Solar Charger for 12/24Vdc Batteries

Brand Name:	Melin Sunergy
Model Number:	MD1230N05
MOQ:	10
Payment Terms:	TT,West Union
Supply Ability:	5000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE ,FCC ,UKCA

MPPT Voltage Range:

17～36Vdc

Max.Alternator Input Voltage:

13.2~16Vdc / 26.4~32Vdc Or 12~16Vdc / 24~32Vdc

Operating Temperature Range:

-35°C~65°C（-31℉～149℉）

Rated Battery Voltage:

12Vdc

Starter Battery Rated Voltage:

12/24Vdc

STARTER BATTERY TYPE:

Lead-acid

Protection Degree:

IP32

Warranty:

3 Years

Supply Ability:

5000pcs per month

Highlight:

DC DC Charger MPPT

IP32 DC DC Charger

MPPT Solar Charger 30A lightweight

Product Description

IP32 DC DC Charger MPPT Solar Charger 30A

Compact and lightweight 30A MPPT solar charger with IP32 protection, designed for 12/24Vdc battery systems. Weighing only 1.92kg, this versatile charger efficiently captures solar energy with advanced MPPT technology.

Product Overview

The DC DC Charger is a compact and lightweight device designed for efficient battery charging in various applications. With MPPT technology that achieves over 99% tracking efficiency, it maximizes solar energy capture even in low-light conditions.

Key Features

MPPT Voltage Range: 17～36Vdc
Maximum Charging Current: 30A
Battery Voltage Range: 9~16Vdc
Lightweight Design: 1.92kg (4.23 Lb)
Multiple Communication Options: TTL, Remote Switch, Bluetooth with APP
IP32 Protection Rating
Compatible with Lead-acid, Li-ion, and User Defined batteries
Optimized for LiFePO4 battery systems

Technical Specifications

Model	MD1230N05
Max. PV Voltage of Open Circuit	55V
MPPT Voltage Range	17～36Vdc
Max. PV Input Power	400W
Max. MPPT Charging Current	30A
Max. Alternator Charging Current	35A
Rated Battery Voltage	12/24Vdc
MPPT Tracking Efficiency	>99%
Max. Charging Conversion Efficiency	98%
Dimensions	221×175.8×92.4mm (8.7×6.9×3.63in)
Operating Temperature	-35°C to 65°C (-31℉ to 149℉)
Warranty	3 Years

Applications

Caravans and mobile homes
Boats and yachts
Off-grid solar systems
Remote power systems
Electric vehicles

Ordering Information: Minimum order quantity: 10 units | Delivery: 15 days | Supply capacity: 5000 units per month | Payment Terms: TT, West Union
