products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
MPPT Solar Charge Controller
Created with Pixso.

High Efficiency 150V Input MPPT Solar Charge Controller with 17 Load Modes and 99.9% Tracking Efficiency

Name

High Efficiency 150V Input MPPT Solar Charge Controller with 17 Load Modes and 99.9% Tracking Efficiency

Brand Name: Melin Sunergy
Model Number: MT508-40A
MOQ: 10
Payment Terms: T/T,Western Union,L/C
Supply Ability: 10,000pcs per month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE ,FCC
Mppt Tracking Efficiency:
>99%
Rated Current:
40A
Model:
MT508-40A
Communication Port:
TTL ,RS485 ,CAN
Display:
LCD
Historical Data:
Past 300 Days
Weight:
2.3Kgs
Max PV Voltage:
150V
Packaging Details:
Inner box + out carton
Supply Ability:
10,000pcs per month
Highlight:

MPPT Based Solar Charge Controller 150V

,

High Voltage Solar Charge Controller 40A

,

High Voltage MPPT Charge Controller 150V

Product Description
High Voltage MPPT Based Solar Charge Controller 150V Input MT508-40A
The MT508-40A MPPT Solar Charge Controller is an essential component in solar power systems, ensuring optimal panel efficiency and proper battery charging. This high-performance controller handles up to 150V PV voltage and 40A charging/discharge current.
Key Features
  • MPPT technology with 99.9% tracking efficiency
  • Programmable settings for customized charging parameters
  • Supports multiple battery types: AGM, gel, flooded, lithium, and user-defined
  • 17 different load operating modes for versatile applications
  • Built-in protection against overcharge, over-discharge, and short-circuit
  • LCD display showing real-time system data
  • Compact design (260×216×83mm) weighing only 2.3kg
  • Communication ports: TTL, RS485, CAN
Technical Specifications
Parameter Value
Product Type MPPT solar controller
Battery Type USE/FLD/GEL/LI/SLD (Default)
Rated Current 40A
Max Input PV Power 520W @12V, 1040W @24V
System Voltage 12V/24V Auto working
Max Input Voltage 150V Voc
MPPT Efficiency 99.9%
Load Operation Modes Light-dependent, time-dependent, manual, debugging, normally opened
Communication TTL, RS485, CAN, Bluetooth
Dimensions 260×216×83mm
Weight 2.3kg
Warranty 3 Years
Applications
The MT508-40A is suitable for various solar applications including:
  • Solar Home Systems: Efficient energy conversion for household appliances
  • Solar Street Lights: Optimized charging for nighttime illumination
  • Solar Water Pumps: Light-dependent control for water flow management
  • Solar Caravans: Reliable power for mobile applications
Customization Options
The controller offers extensive customization capabilities:
  • Fully programmable parameters for advanced users
  • Pre-set default programs for easy setup
  • OEM services available for branding
  • ODM services for specialized requirements
Frequently Asked Questions
Q: What happens if I connect a solar panel with higher wattage than recommended?
A: The controller includes over-power protection and will limit input power without causing damage.
Q: What is the maximum input voltage?
A: The MT508-40A supports up to 150V Voc input.
Q: Can I limit daily operating time for loads?
A: Yes, with 17 available load modes including time-based controls.
Q: What is the minimum order quantity?
A: Minimum order is 1 unit.
