| Brand Name: | Melin Sunergy |
| Model Number: | MT508-40A |
| MOQ: | 10 |
| Payment Terms: | T/T, Western Union, L/C |
40A 150V Input LCD Display 12V 24V MPPT Programmable Solar Charge Controller
The MT508-40A is designed for use with 12V or 24V battery systems and can handle a maximum discharge current of 40A. The MPPT technology ensures that your solar panels are operating at their maximum efficiency, which means that you get more power out of your system.
This programmable solar charge controller also features a variety of protection mechanisms to ensure that your system is safe and reliable. It includes overcharge protection, over-discharge protection, over-temperature protection, and short-circuit protection. Additionally, the MT508-40A has a built-in LCD screen that provides real-time monitoring of your system's performance.
The MT508-40A is a highly efficient and reliable MPPT based solar charge controller that is perfect for use in a wide range of solar-powered applications. Whether you are looking to power your off-grid cabin, RV, or boat, this programmable solar charge controller is the perfect solution for your needs.
With its built-in Bluetooth module, you can easily monitor and control your system through your smartphone or tablet. This makes it easy to adjust your system's settings, monitor its performance, and ensure that your battery system is always charged and ready to go.
In summary, the MT508-40A is a high-quality MPPT based solar charge controller that is designed to provide reliable and efficient charging for your solar-powered battery system. With its built-in Bluetooth module, programmable features, and advanced protection mechanisms, it is the perfect solution for your off-grid solar power needs.
| Product Name | 40A 12V 24V MPPT Solar Charge Controller 150V input |
| Product Type | MPPT solar controller |
| Battery Type |
USE/FLD/GEL/LI/SLD(Default)
|
| Rated Current | 40A |
| Maximum Input PV Power |
520W @ 12V system , 1040W @24V system |
| System Voltage | 12V/24V Auto working |
| Maximum Input Voltage | 150V Voc |
| MPPT Tracking Efficiency | 99.9% |
|
Rated load current
|
40A |
|
Load operation mode
|
Pure light-dependent control, light and time-dependent control, manual mode (default), debugging mode, normally opened.
|
| Display | LCD |
|
TTL Communication
|
Baud Rate 9600kps
|
| Bluetooth | Included |
|
RS485 Communication
|
One isolated RS485 communication port, with power output of 5V200mA, baud rate of 9,600kps by default and adjustable.
|
|
Grounding Type
|
Co-negative design and negative grounding
|
|
Historical Data
|
Can store historical data of the past 300 days
|
| Size |
260*216*83mm
|
| Weight | 2.30g |
| Warranty | 3 Years |
This solar charge controller can handle a maximum PV voltage of 150V, making it ideal for use with high voltage solar panels. Its dimensions are 260*216*83mm, making it compact and easy to install in a variety of settings.
One of the key features of the MT508-40A is its programmability. This solar charge controller supports full setting, which means that users can adjust the charging parameters to suit their specific needs. This makes it a versatile charge controller that can be used in a variety of applications.
The MT508-40A is also a common in negative grounding type controller, which makes it safe and easy to install. Additionally, it comes with historical data that allows users to monitor the charging performance over the past 300 days.
Overall, the Melin Sunergy MT508-40A is a reliable and efficient high voltage solar charge controller that is ideal for a variety of applications. Whether you're looking to charge batteries for off-grid systems or power systems in remote locations, this programmable solar charge controller is an excellent choice. The minimum order quantity is 10 units, making it a great option for both small and large-scale projects.
Our Melin Sunergy MT508-40A high voltage solar charge controller is a programmable solar charge controller designed and manufactured in China. It is CE and FCC certified and has a minimum order quantity of 10 units.
The MT508-40A is a mppt based solar charge controller that supports system voltages of 12V and 24V. It has a high mppt tracking efficiency of over 99%, allowing for maximum power output from your solar panels.
With a wide working temperature range of -35℃~+65℃, the MT508-40A is suitable for use in various weather conditions. It also has a weight of 2.3Kgs, making it easy to install and transport.
The MT508-40A offers various load operation modes, including Pure Light-dependent Control, Light And Time-dependent Control, Manual Mode (default), Debugging Mode, and Normally Opened, providing flexibility and customization options for your solar power system.
Q: What is the best feature of this solar charge controller?
A: We think there have several design in this controller could be the best feature in our mind , such as : Built in Bluetooth ,
Programbale fully setting for different system and loadings etc..
Q: How big solar panel can this controller work with ?
A: Max. working with 520W solar panel in 12V system and 1040W solar panel in 24V system .
Q: Where is this product manufactured?
A: This product is manufactured in China.
Q: Is this product certified?
A: Yes, this product is certified with CE and FCC.
Q: What is the minimum order quantity for this product?
A: Customer can even order 1pc from our online store .
